| Model Number | ISA1200 | ISA1500 | ISA1800 | ISA2100 |
| Unit Size (mm) [WxDxH] | 1200x1050x1350 | 1500x1050x1350 | 1800x1050x1350 | 2100x1050x1350 |
| Net Capacity (Pc) [GN1/4] | 12 | 16 | 20 | 24 |
| Temperature Range (°C) | -18~-22 | |||
| Climatic Class | 4 (32°C & 55% R.H) | |||
| Voltage | 220~240V/50Hz | |||
| Controller Type | Digital | |||
| Body Material | AISI 201 & Glass | |||
| Body Thickness (mm) | 80 | |||
| Isolation | Cyclopentane (40kg/m³) | |||
| Door Quantity (Pc) | 2 | 2 | 2 | 4 |
| Chamber Quantity (Pc) | 1 | |||
| Shelf Quantity (Pc) | / | / | / | / |
| Cooling Mode | Forced | |||
| Defrosting Mode | Electric heater | |||
| Rated Power (W) | 950 | 1060 | 1260 | 1260 |
| Compressor (HP) | 1 | 1 1/2 | 2 | 2 |
| Energy Consumption (Kwh/24H) | / | / | / | / |
| Energy Class | / | / | / | / |
| Refrigerant | R404A | |||
| Customized Items | Voltage | |||
The products are designed to using high quality stainless steel, eco friendly insulation material and energy saving electrical parts, to provide the users with cooler food temperature, lower energy cost, easier service after sales for higher product value: more food storage space, food sanitation, lower using cost
The freezers are designed to display the frozen ice cream for retail business
32°C working temperature
Forced air cooling system
60 mm insulation thickness
40 Kg/M³ Ecology friendly insulation material
High efficency compressors
Using R290 refrigerant (environmentally friendly hydrocarbon refrigerant), zero ODP and low GWP
Exterior & Interior 304 stainless steel body material
Digital thermostat, with temperature display
High speed and low noise fan motor
Auto defrosting system
With middle hollow glasses, top glass is with heater for anti-fogging
With back sliding glass door
With LED lighting
The refrigeration system is using R290 (environmentally friendly hydrocarbon refrigerant) with zero ozone depletion potential (ODP) & low global warming potential (GWP).
The refrigeration system has a special designed airflow to provide well-balanced temperature for all trays.
All of the parts of refrigeration system are precisely calculated and matched by our experienced engineers based on the cabinet's space, ambient temperature, cabinet temperature and food temperature, and tested for long time in product performance laboratory to get final system configuration.
The refrigeration system is using high efficiency compressor, high speed & lower power EC fan motors, to make the product save lots of energy consumption comparing to traditional refrigeration system (R404A refrigeration system)
Exterior: high quality 304 stainless steel for front/back, top and sides, bottom panels, corrosion resistant & easy cleaning.
Interior: high quality 304 stainless steel for all sides, corrosion resistant & easy cleaning.
Insulation: with 40mm thickness & 40±2 Kg/M³ high density polyurethane insulation for entire cabinet structure and solid door, zero ozone depletion potential (ODP) and low global warming potential (GWP).
Due to different food service, there is different top types: stainless steel lids, stainless steel table, stainless steel preparation top, marble top
Without door
Without shelves
Voltage: 110V/60Hz, 220V/50Hz, 220V/60Hz ( compressor will be changed)
Refrigerant: R290, R404A (Compressor will be changed)
Cabinet material: 201, 304 stainless steel
Adjustable stainless steel legs: 50mm,100mm, 125mm, 150mm height
Castors with front brakes: 50mm, 100mm, 125mm, 150mm height
Thermostat: Dixell or Chinese brands
Glass: all sides are with heaters
