| Model Number | GNT800TN | GNT800BT | GNT800CH | GNT1600TN2 | GNT1600BT2 | GNT1600CH2 |
| Unit Size (mm) [WxDxH] | 800x900x2200 | 1500x900x2200 | ||||
| Net Capacity (L) | 800 | 1600 | ||||
| Temperature Range (°C) | 0~10 | -22~-18 | 15~25 | 0~10 | -22~-18 | 15~25 |
| Climatic Class | 38 | 4~30 | 38 | 4~30 | ||
| Voltage | 220~240V/50Hz | |||||
| Controller Type | Digital | |||||
| Body Material | AISI 304 | |||||
| Body Thickness (mm) | 60 | |||||
| Isolation | Cyclopentane (40kg/m³) | |||||
| Door Quantity (Pc) | 1 | 2 | ||||
| Chamber Quantity (Pc) | 1 | |||||
| Tray Quantity (Pc) [GN2/1] | 15 | 30 | ||||
| Cooling Mode | Forced air | |||||
| Defrosting Mode | Electrical heater | |||||
| Rated Power (W) | 350 | 980 | 400 | 750 | 1500 | 600 |
| Compressor (HP) | 1/5 | 1 | 1/6 | 1/5*2 | 1*2 | 1/6*2 |
| Energy Consumption (Kwh/24H) | 4.2 | 16.0 | 4.0 | 8.0 | 32.0 | 8.0 |
| Energy Class | / | / | / | / | / | / |
| Refrigerant | R-290 | |||||
| Customized Items | Voltage/Body material/Shelf material/Digital controller/Glass door/Wheel | |||||
The products are designed to using trolley cart, monoblock cooling system, and high quality stainless steel, eco friendly insulation material and energy saving electrical parts, to provide the users with cooler food temperature, lower energy cost, easier service after sales for higher product value: more easy to put food, more food storage space, food sanitation, lower using cost
43°C working temperature
Monoblock cooling system
Forced air cooling system
60 mm insulation thickness
40 Kg/M³ Ecology friendly insulation material
High efficency compressors
Using R290 refrigerant (environmentally friendly hydrocarbon refrigerant), zero ODP and low GWP
Exterior & Interior 304 stainless steel body material
Digital thermostat, with temperature display
High spped and low noise fan motor
Auto defrosting system
Extra thickness door, self-closing
Stainless steel trolley cart, suitable for 15 layers GN2/1 pans
The refrigeration system is designed to Monobloc Cooling System, all parts of refrigeration system are integraded into a whole unit, and put on top of cabinet, the evaporator is not fixed in the cabinet like as traditional refrigeration system, to provide the users with more food stroage space. The repairing and matainance of the refrigeration system is outside of cabinet, no need to take out the foods during product service to ensure the food safety, besides save service time.
The refrigeration system is using R290 (environmentally friendly hydrocarbon refrigerant) with zero ozone depletion potential (ODP) & low global warming potential (GWP).
The refrigeration system has a special designed airflow to provide well-balanced temperature for all trays.
All of the parts of refrigeration system are precisely calculated and matched by our experienced engineers based on the cabinet's space, ambient temperature, cabinet temperature and food temperature, and tested for long time in product performance laboratory to get final system configuration.
The refrigeration system is using high efficiency compressor, high speed & lower power EC fan motors, to make the product save lots of energy consumption comparing to traditional refrigeration system (R404A refrigeration system)
Exterior: high quality 304 stainless steel for front, top and sides, galvanized external back/bottom panels, corrosion resistant & easy cleaning.
Interior: high quality 304 stainless steel for all sides, corrosion resistant & easy cleaning.
With round edges and corners design for cleaning inside.
Insulation: with 60mm thickness & 40±2 Kg/M³ high density polyurethane insulation for entire cabinet structure and solid door, zero ozone depletion potential (ODP) and low global warming potential (GWP).
High quality 304 stainless steel exterior & interior.
Extra thickness & high-density polyurethane insulation.
With removable multi-airbag door gasket.
With long recessed door handle.
Self-closing door with 120° opening and stopping.
Without shelves, but with stainless steel trolley
GN2/1 pans can be put on the trolley
Voltage: 110V/60Hz, 220V/50Hz, 220V/60Hz ( compressor will be changed)
Refrigerant: R290, R404A (Compressor will be changed)
Cabinet material: 201, 304 stainless steel
Shelf: Stainless steel & plastic coated wire
Adjustable stainless steel legs: 100mm, 125mm, 150mm height
Castors with front brakes: 100mm, 125mm, 150mm height
Thermostat: Dixell or Chinese brands
Door handle: can be customized
Top panel: can be customized
Glass door for chiller: 2 layer middle hollow tempered glasses, aluminum frame, aluminum door handle, with or without anti-fogging heater
Glass door for freezer: 3 layer middle hollow tempered glasses, aluminum frame, aluminum door handle, with anti-fogging heater
Pass-through for trolley cart
