| Model Number | VRX1200-335 | VRX1350-335 | VRX1500-335 | VRX1800-335 | VRX2000-335 | VRX1200-395 | VRX1350-395 | VRX1500-395 | VRX1800-395 | VRX2000-395 |
| Unit Size (mm) [WxDxH] | 1200x335x425 | 1350x335x425 | 1500x335x425 | 1800x335x425 | 2000x335x425 | 1200x395x425 | 1350x395x425 | 1500x395x425 | 1800x395x425 | 2000x395x425 |
| Pan Quantity (L) [GN1/4 or GN1/3] | 5 | 6 | 7 | 9 | 10 | 4 | 5 | 6 | 8 | 9 |
| Temperature Range (°C) | 0~10 | 0~10 | ||||||||
| Climatic Class | 4 (32°C & 55% R.H) | 4 (32°C & 55% R.H) | ||||||||
| Voltage | 220~240V/50Hz | 220~240V/50Hz | ||||||||
| Controller Type | Digital | Digital | ||||||||
| Body Material | AISI 201 | Coated steel | ||||||||
| Body Thickness (mm) | 45 | 45 | ||||||||
| Isolation | Cyclopentane (40kg/m³) | Cyclopentane (40kg/m³) | ||||||||
| Door Quantity (Pc) | / | / | / | / | / | / | / | / | / | / |
| Chamber Quantity (Pc) | 1 | 1 | ||||||||
| Shelf Quantity (Pc) | / | / | / | / | / | / | / | / | / | / |
| Cooling Mode | Static | Static | ||||||||
| Defrosting Mode | Auto | Auto | ||||||||
| Rated Power (W) | 145 | 145 | 145 | 145 | 145 | 145 | 145 | 145 | 145 | 145 |
| Compressor (HP) | 1/8 | 1/8 | 1/8 | 1/8 | 1/8 | 1/8 | 1/8 | 1/8 | 1/8 | 1/8 |
| Energy Consumption (Kwh/24H) | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 |
| Energy Class | / | / | / | / | / | / | / | / | / | / |
| Refrigerant | R-290 | R-290 | ||||||||
| Customized Items | Voltage/Body material/Digital controller/Stainless steel pan cover/Curved glass pan cover | |||||||||
The products are designed to using high quality stainless steel, eco friendly insulation material and energy saving electrical parts, to provide the users with cooler food temperature, lower energy cost, easier service after sales for higher product value: food sanitation, lower using cost
The products are designed for food service to display refrigerated salad, sandwich, food ingredients
32°C working temperature
Static cooling system
40 mm insulation thickness
40 Kg/M³ Ecology friendly insulation material
High efficency compressors
Using R290 refrigerant (environmentally friendly hydrocarbon refrigerant), zero ODP and low GWP
Exterior & Interior 304 stainless steel body material
Digital thermostat, with temperature display
High spped and low noise fan motor for condenser
Auto defrosting system
With 8mm thickness tempred glass cover
Suible for GN1/4 , GN1/3, GN1/6 pans
The refrigeration system is using R290 (environmentally friendly hydrocarbon refrigerant) with zero ozone depletion potential (ODP) & low global warming potential (GWP).
The refrigeration system has a special designed airflow to provide well-balanced temperature for all trays.
All of the parts of refrigeration system are precisely calculated and matched by our experienced engineers based on the cabinet's space, ambient temperature, cabinet temperature and food temperature, and tested for long time in product performance laboratory to get final system configuration.
The refrigeration system is using high efficiency compressor, high speed & lower power EC fan motors, to make the product save lots of energy consumption comparing to traditional refrigeration system (R404A refrigeration system)
Exterior: high quality 304 stainless steel for all sides, corrosion resistant & easy cleaning.
Interior: high quality 304 stainless steel for all sides, corrosion resistant & easy cleaning.
Insulation: with 40mm thickness & 40±2 Kg/M³ high density polyurethane insulation for entire cabinet structure and solid door, zero ozone depletion potential (ODP) and low global warming potential (GWP).
Without doors, but with glass cover to display the refrigerated salad, sandwich, food ingredients
No shelves, but with pan deviders to avoid the gas between the pans
Voltage: 110V/60Hz, 220V/50Hz, 220V/60Hz ( compressor will be changed)
Refrigerant: R290
Cabinet material: 201, 304 stainless steel
Thermostat: Dixell or Chinese brands
Stainless steel lid
Curved glass cover
